| Type |
Desktop |
| Engine speed (colour & B/W) |
A4 (8 1/2" x 11")*1: Max. 24 ppm, A3 (11" x 17"): Max. 12 (11) ppm |
| Control panel display |
Custom LCD |
| Paper size |
Max. A3 (11" x 17"), min. A6 |
| Paper capacity(80 g/m²) |
Standard:350 sheets (250-sheet tray and 100-sheet multi-bypass tray),Maximum:1850 sheets(350 sheets & optional 500 sheet trayx3) |
| Paper weight |
Tray: 55 g/m2 to 105 g/m2, Multi-bypass tray: 55 g/m2 to 200 g/m2 |
| Warm-up time |
25 sec. |
| Memory |
Standard: 64 MB, Maximum: 448 MB |
| Power requeirements |
Rated local AC voltage ±10%, 50/60 Hz |
| Power consumption |
Max. 1.2 kW |
| Dimensions(W×D×H) including document cover |
599 x 612 x 511 mm |
| Weight(approx.) |
28 kg |
| COPIER (-) |
| Original size |
Max. A3 (11" x 17") |
| First copy time |
A4: 6.4 seconds, 8 1/2" x 11": 6.5 seconds |
| Resolution |
600 x 600 dpi |
| Continuous copy |
Max. 999 copies |
| Gradation |
256 levels |
| Zoom range |
25% to 400% (50% to 200% using RSPF) in 1% increments |
| Preset copy rations |
Metric: 10 ratios (5R/5E), inch: 10 ratios (5R/5E) |
| NETWORK PRINTER (-) |
| Memory |
- |
| Resolution |
600 x 600 dpi |
| Interface |
USB 2.0 (host, high-speed), 10Base-T/100Base-TX |
| Network protocols |
TCP/IP |
| Printing protocols |
- |
| PDL |
SPLC (Sharp Printer Language with Compression), PCL 6 emulation, PostScript® 3™ emulation |
| Supported OS |
Windows Server® 2012, Windows Server® 2012 R2, Windows Server® 2016, Windows Server® 2019, Windows® 8.1, Windows® 10, Mac OS 10 |
| Available fonts |
80 fonts for PCL, 136 fonts for PostScript 3 emulation |
| COLOUR SCANNER (-) |
| Resolution |
- |
| File formats |
- |
| Protocols |
- |
| Scanner utility |
- |
| Network Scanner (-) |
| Scan method |
- |
| Scan speed |
- |
| Resolution |
Push scan: 75, 100, 150, 200, 300, 400, 600 dpi Pull scan: 75, 100, 150, 200, 300, 400, 600 dpi; 50 dpi to 9,600 dpi via user se |
| File formats |
TIFF, PDF, JPEG, BMP |
| Scanner utility |
- |
| Scan destinations |
Scan to e-mail/desktop/FTP server/USB drive |
